40dB 30dB 20dB 15dB 10dB 7dB 6dB 5dB 136-174MHz VHF Coupler N Female Cavity RF Directional Coupler for IBS DAS

Short Description:

VHF directional coupler operates within a frequency range of 136 to 174 MHz, offering coupling options of 6 dB, 10 dB, 15 dB, 20 dB, 30 dB, and 40 dB, making it highly suitable for IBS DAS applications. It features an N female connector and supports coupling levels from 6 to 30 dB, ideal for DAS/IBS and broadband signal sampling. Feature 1.High Isolation 2.Multi-Band Frequency Coverage 3.High Average Power Rating 4.Multiple IP Degree Conditions 5.Low Cost Design 6.N /DIN/ 4.3-10 Connectors 7...

Brand: Kingtone/JIMTOM

Min.Order Quantity: 1 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Warranty: 12months

5dB Coupler: 6dB Coupler

7dB Coupler: 10dB Coupler

15dB Coupler: 20dB Coupler

30dB Coupler: 40dB Coupler

Send email to us Download as PDF

Product Detail

Product Tags

Feature

1.High Isolation

2.Multi-Band Frequency Coverage

3.High Average Power Rating

4.Multiple IP Degree Conditions

5.Low Cost Design

6.N /DIN/ 4.3-10 Connectors

7.Customer Design Available

Specification below:

Coupling(dB)	5±0.9	6±0.9	7±0.9	10±1.1	15±1.2	20±1.2	30±1.5	40±1.5
Insertion Loss(dB)	≤2.3dB	≤1.7dB	≤1.4dB	≤0.8 dB	≤0.4dB	≤0.3 dB	≤0.2 dB	≤0.20 dB
Isolation(dB)	23 dB	24 dB	25dB	30dB	35dB	40dB	50dB	60dB
Frequency(MHz)	136-174MHz
VSWR	≤1.25:1
Power(W)	200W
Impedance(ohm)	50Ω
Connector	N-female
Temperature(deg)	-40℃ ~ +80℃
Color	Black
Application	Indoor
