Kingtone Outdoor Cell Phone Extender 5km Range Cell Signal Repeater 850 Mhz Mobile Network Band 5 Signal Booster 2G 3G 4G
Kingtone Mobile Network Coverage Signal Booster Gsm 3G 4G 850MHz Gsm Signal Repeater Booster Amplifier is designed to solve problems of weak mobile signal, which is much cheaper than adding a new base station (BTS).Main operation of the repeaters are to receive lower-power signal from BTS via RF transmission and then transmit the amplified signal to the areas where network coverage is inadequate.And the mobile signal is also amplified and transmitted to the BTS via the opposite direction.
Features:
1,Output Power +30dBm - +43dBm for large coverage application;
2,High working gain as Min. 95dB;
3,Adopting filter with highly selectivity and low insertion loss eliminates interference between uplink and downlink;
4,RS232 ports provide links to laptop for local setting and monitoring by built-in web interface;
5,Built-in wireless modem (Option) for remote monitoring by SMS or GPRS;
6,Details repeater parameters and status can be monitoring by Control Panel, such as temperature, output power level, gain, ATT, return loss, VSWR etc;
7,Support upgrading firmware remotely by GPRS;
8,High gain linear power amplifier technique with reliable performance;
9,Compact size and light weight, easy to install on wall or pole;
Typical Application:
Kingtone Outdoor Mobile Network Coverage Signal Booster Gsm 3G 4G 850MHz Gsm Signal Repeater Booster Amplifier to expand signal coverage of fill signal blind area where signal is weak or unavailable.
Outdoor: Airports, Tourism Regions, Golf Courses, Tunnels, Factories, Mining Districts, Villages etc.
Indoor: Hotels, Exhibition Centers, Basements, Shopping Malls, Offices, Packing Lots etc.
Standard Package
1) Kingtone Mobile Network Coverage Signal Booster Gsm 3G 4G 850MHz Gsm Signal Repeater Booster Amplifier (AC power cord EU standard/ US standard/ UK standard) 1PC
2) Installation kit 1PC
3) User manual 1PC
Recommended Accessories
1) Donor antenna: Outdoor Panel Antenna ( 12dBi, 824-960Mhz )
2) Service antenna: Omni Ceiling Antenna ( 3dBi,824-960MHz)
3) 1/2" RF cable with connecter ( Cable length optional)
4) Splitter, coupler
Technical Specification:
| Item | Mobile Network Coverage Signal Booster Gsm 3G 4G 850MHz Gsm Signal Repeater Booster Amplifier | ||
| Frequency Range | Uplink | 824-849MHz | |
| Downlink | 869-894MHz | ||
| Output
Power |
Uplink | +33dBm | |
| Downlink | +40dBm | ||
| Working Bandwidth | Various bandwidth is available upon request | ||
| Gain | Min. 90dB | ||
| Gain Control Range | 31dB (1dB Step) | ||
| VSWR | < 1.5 | ||
| Ripple in Band | Max +/- 1.5dB | ||
| Spurious
Emissions |
9KHz-1GHz | Max -36dBm | |
| 1GHz-12.75GHz | Max -30dBm | ||
| ACPR | ≤-45dBc | ||
| ≤-55dBc | |||
| RF Connector | N-type Female | ||
| I/O Impedance | 50 ohm | ||
| Noise Figure | Max 5dB | ||
| Group Time Delay | Max 5µS | ||
| Temperature Range | -25 degree Celsius to +55 degree Celsius | ||
| Relative Humidity | Max 95% | ||
| MTBF | Min. 100000 hrs | ||
| Power Supply | DC -48V / AC220V (+/-15%), 50Hz | ||
| UPS Backup Power Supply (Optional) | 6 hours / 8 hours | ||
| Power Consumption | Max 250W | ||
| NMS Monitor Function | Real-time alarm for Door Status, Temperature, Power Supply, VSWR,
Output Power, Gain, Uplink ATT, Downlink ATT and etc. |
||
| Remote Control Module (Optional) | RS232 or RJ45 + Wireless Modem + Chargeable Li-ion Battery | ||
Why Choose Kingtone?
Since 2006, Kingtone has been developing and manufacturing Repeaters included CDMA Repeater, GSM Repeater,DCS Repeater, PCS Repeater, UMTS(W-CDMA) Repeater, Tetra Repeater, iDEN Repeater, Wimax Repeater and 4G LTE Repeater etc. Moreover, Kingtone Repeater have different types included Full Band-selective Repeater, Channel-selective Repeater, Frequency-shifting Repeater, Fiber-optical Repeater, Trunk-amplifier etc. The repeaters can be Single-band Repeater, Dual-band Repeater and Tri-band Repeater etc. The Multiple Bands for different Mobile Operators.
As well as the repeater, the passive circuits such as Power Splitters, Directinal Couplers, POI, Connectors, Antennas etc. are in operation.
At Present, Kingtone exhibited the highest quality products and enterprise’s comprehensive strength. And Kingtone continues to strengthen technological innovation on repeater products and will launch the new products on the market soon.
With your supports and new requirements which can make us improve our service, innovative our technology and consummate the products.
OEM & ODM are welcome!
